Technical Parameters
| Design volume | 25 mL, 50 mL, 100 mL, |
| Design temperature | Standard 300 ℃ |
| Heating mode | Embedded stainless steel heating module |
| Stirring speed | 400-1400 rpm (stepless speed regulation) |
| Stirring method | High-torque magnetic coupling stirring or built-in magneton stirring |
| Design pressure | Standard 207 bar (optional) |
| Material of reactor | 316 L stainless steel, Hastelloy C-276,etc.(optional) |
| Control mode | 10-inch touch screen,displaying the temperature,rotation speed,pressure and operating time |
| Personalized options | Various reactor vessel materials, stirring forms, sampling, cooling, and reflux condensation |
| Outline dimension | 1050*600*650 mm |
The Selection of Kemi reactor could be based on the following four basic parameters.
(1) Maximum working pressure
The design working pressure is 207bar for reactor < 500ml . Kemi produce the reactor whose maximum working pressure is 350 bar. Kemi could also produce customized reactor according to different requirements.
(2) Maximum operating temperature
The design operating temperature of the conventional reactor is 300℃ (sealed with reinforced PTFE flat gasket) and maximum temperature is 550℃ (sealed with Grafoil graphite gasket), the operating temperature can be adjusted according to customer requirements.
(3) Capacity selection
The capacity of Kemi reactor ranges from 10ml to 500mL . The volume here refers to the maximum volume of the reactor, Generally, the liquids should not exceed 2/3 of the volume of the reactor.
(4) Material selection
The material of Kemi regular reactor is 316L stainless steel and Hastelloy C-276, and other materials are also available:
– Industrial Titanium TA2
– Zirconium alloys 702, 705
– Other required metal materials
Kemi Reactors and Pressure vessels could meet most demands of chemical experiments for high temperatures and pressures reaction environments.
Different design solutions can be provided according to different requirements. Kemi will provide conventional configuration if there was no special requirements. For special requirements, please communicate with us and our technician can give you good solution.
Product Details
Safety
Adopt integrated machine shaping structure
Tenon-groove type main sealing structure;
Over-temperature automatic power-off;
Over-pressure buzzer alarm;
Fitok import relief valve and customized rupture valve, providing double protection.
Accurate
Intelligent PID temperature control mode;
Digital display stepless speed regulation;
Embedded heating module with faster heat transfer.
Efficient
Quick-opening structure;
Power-assisted disassembly tools;
7-inch sensitive touch screen;
Concise and intuitive UI man-machine interface;
USB interface for data download.
Portable
Integrated design;
V-stem portable needle valve with customized coating;
Minimize the weight of the reactor on the premise of ensuring safety.
