Muti-Channel Gas Distribution Mixing System Device Gas Mixers

The gas mixer can regulate the ﬂow of diﬀerent gases through the mass ﬂow meter and mix them in appropriate proportions. Gas cleaning unit can be also added as needed by the experiment. The mass ﬂow meter shall be installed in sealed pipe box and connected with duplex stainless steel tube and precision double-ferrule ﬁtting. The touch screen control equipment can be used in conjunction with Kemi tube furnaces.

Inquire Now

Contact Us

Phone:
+86 198 5665 9753
Email:
kemisale02@ahkemi.com
WhatsApp:
+8619856659753

WhatsApp:
+8619856659763
Address:
Intersection of Shuanglong Road and Wangke Road, Economic Development Zone, Hefei City, Anhui Province.

Product introduction
FAQ

Technical Parameters

Adaptive power	AC220 V 50/60 HZ
Standard range of the ﬂow meter	100sccm/200sccm/200sccm/500sccm (Unless otherwise speciﬁed, it shall be calibrated with nitrogen. Ranges are selectable)
Operating temperature	5~45 ℃
Operating pressure diﬀerence	0.1~ 0.5 MPa
Operating pressure	Flowmeter pressure 3MPa, system outlet pressure = <0.3MPa(other non-standard pressure, must be customised)
Precision	±1.5% FS
Measuring range	-0.1~0.15 MPa (0.01 MPa/grid)
Needle valve	316 stainless steel
Stop valve	316 stainless steel needle valve
Size	260450450 mm

Are you a manufacturer?

Yes, we are laboratory instruments manufacturer, our main products are pressure vessels like stirring reactors, photocatalytic reactors, hydrothermal reactors, tube furnaces and box furnaces.
Can you customize the logo and packaging?

Yes, We have professional product design, research and development personnel. We can complete the design，production and delivery according to your requirements.
Is there any technical support I can get?

You can contact us at anytime if you don't know how to use our products, operation video or technical staff online guidance will be provided.
