High Pressure Stainless Steel Magnetic Stirring Autoclave Reactor Manufacturer

NSG universal quick-opening magnetic stirring reactor is configured with the magnetic stirrer and intelligent temperature control module, realizing accurate stirring and temperature control.

Design volume	25 mL, 50 mL, 100 mL, 300 mL, 500 mL
Maximum operating temperature	Standard 300 ℃
Heating mode	Embedded stainless steel heating module
Heating power	1 kW
Stirring speed	400-1400 rpm (stepless speed regulation)
Stirring method	Built-in magneton stirring
Design pressure	Standard 207 bar (optional)
Material of reactor	316 L stainless steel, Hastelloy C-276,etc.(optional)
Personalized options	Various alloy materials, stirring forms, sampling and cooling, etc.optional configurations
Outline dimension	NSG25/50/100 mL: 410360500 mm

The Selection of Kemi reactor could be based on the following four basic parameters.
(1) Maximum working pressure
The design working pressure is 207bar for reactor < 500ml, 103bar for Photocatalysis reactor. Kemi produce the reactor whose maximum working pressure is 345bar. Kemi could also produce customized reactor according to different requirements.
(2) Maximum operating temperature
The design operating temperature of the conventional reactor is 300℃ (sealed with reinforced PTFE flat gasket) and maximum temperature is 550℃ (sealed with Grafoil graphite gasket), the operating temperature can be adjusted according to customer requirements.
(3) Capacity selection
The capacity of Kemi reactor ranges from 10ml to 29L. The volume here refers to the maximum volume of the reactor, Generally, the liquids should not exceed 2/3 of the volume of the reactor.
(4) Material selection
The material of Kemi regular reactor is 316L stainless steel and Hastelloy C-276, and other materials are also available:
– Industrial Titanium TA2
– Zirconium alloys 702, 705
– Other required metal materials

Kemi Reactors and Pressure vessels could meet most demands of chemical experiments for high temperatures and pressures reaction environments.
Different design solutions can be provided according to different requirements. Kemi will provide conventional configuration if there was no special requirements. For special requirements, please communicate with us and our technician can give you good solution.

Product Details

Safety

It adopts integrated machine shaping structure;
Tenon-groove type main sealing structure;
Supports the over-temperature automatic power-off;
Provide double protection through imported Fitok import relief valve and customized rupture valve

Accurate

Intelligent PID temperature control mode;
Digital display stepless speed regulation;
Embedded heating module with faster heat transfer.

Portable and Efficient

Minimize the weight of the reactor on the premise of ensuring safety;
Quick-opening structure;
Power-assisted disassembly tools.
